6KVA 5KW 3 Phase Voltage Stabilizer 380V AC Automatic Voltage Regulators

Name: 6KVA 5KW 3 Phase Voltage Stabilizer 380V AC Automatic Voltage Regulators
Brand: SHLEIPUSI Or Support OEM/ODM Service
Price: 1 USD

Quality 6KVA 5KW 3 Phase Voltage Stabilizer 380V AC Automatic Voltage Regulators for sale

Brand Name : SHLEIPUSI Or Support OEM/ODM Service

Model Number : TNS-6KVA Or Customized

Certification : CE;ISO9001;UL

Place of Origin : Shanghai

MOQ : 1

Price : 1 pc≤Qty≤5 pcs 160USD; 5 pcs＜Qty≤100 pcs 155USD; 100pcs＜Qty 150USD

Payment Terms : T/T,D/P,D/A,L/C,Western Union

Supply Ability : 1000000PCS

Delivery Time : 1 pc≤Qty≤5 pcs 1-7 working days; 5 pcs＜Qty≤100 pcs 7-14 working days; 100pcs＜Qty More than 14 working days

Packaging Details : Non-fumigation plywood case ; Reference packing size: 40X42X80CM; Reference weight: 40KG

Product name : 380V 3 Phase AC Automatic Voltage Regulators

Place of origin : Shanghai, PRC

Rated capacity : 6KVA Or Customized

Product model : TNS-6KVAOr Customized

Rated input voltage : 380VAC±20% Or Customized

Rated Output voltage : 380V Or Customized

Output precision : ±1～2%

Working temperature : －15℃~＋45℃

Contact Now

380V 3 Phase AC Automatic Voltage Regulators | TNS Series Industrial Voltage Stabilizer

Product Overview

Our 380V 3 Phase AC Automatic Voltage Regulators (TNS/SVC series) are industrial-grade stabilization solutions engineered for global industrial applications, with standard rated capacity from 6KVA to 120KVA (fully customizable). With a standard input range of 304V-456V (line-to-line) and 176-264V auxiliary range, this regulator is built with premium copper coils, high-torque servo motors, intelligent auto-control circuits, and high-conductivity carbon brushes. When grid voltage fluctuates or load changes, the control system drives the servo motor to adjust the carbon brush position, maintaining a stable 380V output continuously. It delivers zero additional waveform distortion, reliable 24/7 operation, and is ideal for factory power systems, CNC machine tools, photovoltaic systems, AI data centers, EV charging stations, generators, and precision industrial equipment.

Key Features & Competitive Advantages

High Precision & Fast Response: Microcomputer control board with sub-modulation technology ensures ±2% output accuracy, with rapid servo-driven adjustment to stabilize voltage in milliseconds, eliminating unplanned downtime for sensitive equipment.
Durable & High-Efficiency Design: Full purple copper coils with tight, standardized winding minimize power losses, while double high-conductivity carbon brushes extend service life, delivering full rated capacity, low energy consumption, and long-term reliable operation.
Comprehensive Protection System: Built-in over-voltage, under-voltage, over-current, overload, short-circuit, and surge protection to safeguard your valuable industrial equipment from grid anomalies and voltage spikes.
User-Friendly & Versatile: Equipped with brake wheels for flexible on-site mobility, highly insulated reliable terminals, optional pointer or digital display for real-time monitoring, and full compatibility with resistive, inductive, and capacitive loads for diverse industrial scenarios.

Why Choose Our Voltage Regulators

As a professional manufacturer of 380V 3 Phase AC Automatic Voltage Regulators, we deliver end-to-end solutions for global B2B customers. We offer full OEM/ODM customization, including tailored product parameters, appearance, logo printing on products and manuals, and custom packaging. Every unit undergoes strict pre-shipment testing to ensure zero defects, with a monthly production capacity of 10,000 low-power units and 2,000 high-power units to meet bulk order demands. We provide flexible global shipping options covering all mainstream trade terms, plus lifetime free technical support, on-site installation guidance, and free component replacement for warranty-covered quality issues. We also offer free professional product photography and video services to support your marketing needs.

Technical Specifications

Parameter	Standard Specification	Customization Option
Product Name	380V 3 Phase AC Automatic Voltage Regulators	Fully Customizable
Model	TNS-6KVA	6KVA-120KVA Customized
Rated Frequency	50/60Hz	Customizable
Input Voltage	304-456VAC (Line to Line)	Custom Wide Range
Output Voltage	380V±2% (Line to Line)	Custom Voltage
Phase Configuration	3 Phase 4 Wires (3P+N+G)	Customizable
Working Temperature	-10°C to +45°C	Extended Range
Display Mode	Pointer Meters / Digital Display	Customizable

6KVA 5KW 3 Phase Voltage Stabilizer 380V AC Automatic Voltage Regulators

Frequently Asked Questions (FAQ)

What is your order lead time?

Normally 3-7 working days for standard orders; 10-30 days for customized or bulk orders based on specific specifications.
How do you control product quality?

Our professional QC team monitors raw material incoming inspection and the full manufacturing process. All products pass strict performance and safety testing before shipment.
What are your payment terms?

30% deposit for standard products, 50% advance payment for customized models, with the full balance settled before shipment.
Do you provide technical support for product installation?

Yes. Our professional engineering team offers full installation and application guidance, including video support, on-site debugging, and lifetime free telephone guidance.
What packaging do you use for your products?

Large-capacity models use reinforced wooden cases for transportation protection, while small models use high-strength cartons. Custom packaging is available on request.
Do you accept OEM and ODM services?

Yes. We support full OEM/ODM solutions, including custom logo printing on products, user manuals, and technical documents for bulk orders.
What are your main global markets?

Our products are sold worldwide, covering core markets in Central Asia, East Asia, South Asia, Africa, South America, and North America.
What is your monthly production capacity?

We produce approximately 10,000 units monthly for low-power models, and 2,000 units monthly for high-power industrial voltage regulators.
What is your minimum order quantity (MOQ)?

Our MOQ is 1 set for both standard and customized models, fully supporting sample orders and project trial demands.
