Distribution Cabinet Transformer | PLG Series 3 Phase Dry Type Voltage Transformer
Contact Us
Tel: +86 15926315252 | Mobile/WeChat: +86 15926315252
Email: daniel@shlepus.com | WhatsApp: +86 18979230829
Product Introduction
Our Distribution Cabinet Transformer (PLG series) is a specialized 3 phase dry type voltage transformer purpose-built for seamless integration into power distribution cabinets and industrial electrical systems. With a standard rated capacity of 40KVA and a customizable range from 500VA to 2000KVA, it supports standard 3 phase 220V/380V input and output, with fully customizable voltage configurations to meet diverse project requirements. Rated for 50Hz/60Hz AC circuits with operating voltage up to 1000V, it is the ideal power solution for low-voltage distribution systems. Trusted by electrical engineers, factory operators and medical facility managers worldwide, this distribution cabinet transformer is perfectly suited for hospitals, factory power distribution, CNC machine tools, photovoltaic systems, power transmission equipment, precision instrumentation, generators, industrial motors and EV charging stations.
Key Features & Competitive Advantages
Engineered for reliable cabinet-integrated operation, our distribution cabinet transformer delivers exceptional long-term performance and energy efficiency. Core benefits include full-capacity continuous operation, ultra-low temperature rise, minimal energy losses and an energy-saving design enabled by a high-permeability silicon steel core for noise-free operation (<55dB) and high magnetic flux. It adopts high-purity winding material for superior conductivity and reduced heat generation, with high-grade insulation materials that withstand 3500V dielectric strength tests and a premium nylon frame for stable insulation performance. Designed for safe and convenient use, it features a digital display for real-time working status monitoring, a safety trip lock, brake-equipped universal wheels, input/output indicator lights, high-efficiency heat emission holes, reliable high-insulation terminals, strong electrical conductivity, user-friendly wiring design, and IP23 protection grade, with full compliance with global environmental standards.
Why Choose SHLEIPUSI
As a professional distribution cabinet transformer manufacturer serving the global market, we deliver tailored end-to-end power solutions meeting international quality benchmarks. We offer comprehensive OEM/ODM services, including custom capacity, voltage, appearance, logo branding and packaging, with free professional product photography and video services for bulk orders. Every unit undergoes strict multi-stage quality inspection from raw material intake to final factory testing, ensuring zero defects and consistent performance. We support worldwide shipping via sea, air, land, express and railway, with all mainstream Incoterms available. Our after-sales service includes lifetime free technical guidance, video/on-site installation support, and free replacement of components damaged by manufacturing defects during the warranty period. With a monthly capacity of 10,000 small-power units and 2,000 large-power models, we accommodate flexible orders with a minimum order quantity of just 1 set.
Technical Specifications
| Parameter |
Core Specification |
Fully Customizable |
| Product Name |
Distribution Cabinet Transformer |
Yes |
| Model |
PLG-40KVA |
Yes |
| Rated Capacity |
40KVA |
Yes |
| Rated Input Voltage |
3 Phase 220V/380V |
Yes |
| Rated Output Voltage |
3 Phase 220V |
Yes |
| Working Frequency |
50/60Hz |
Yes |
| Output Precision |
±2% |
Yes |
| Insulation Class |
F |
Yes |
| Working Efficiency |
≥90% |
Yes |
| Cooling Method |
Dry Type Air Cooling |
Yes |
| Protection Class |
IP23 |
Yes |
| Noise Level |
＜55dB |
Yes |
Frequently Asked Questions (FAQ)
- Is this distribution cabinet transformer suitable for standard power distribution cabinet installation?
Yes, it is specially designed for seamless integration into standard and custom power distribution cabinets, with customizable dimensions and configurations to match your cabinet design.
- What is the lead time for distribution cabinet transformers?
Standard models ship within 3-7 working days; custom orders take 10-30 days based on quantity and specifications.
- How do you control the product quality of your transformers?
We conduct professional quality inspection at every production stage from raw material incoming to final testing, and only qualified products are shipped.
- What are your accepted payment terms?
30% deposit for standard products, 50% advance payment for custom orders, with full balance settled before shipment.
- Do you provide technical support for product installation and cabinet integration?
Yes, our professional technical team offers full installation and integration guidance, including remote video and on-site support.
- What packaging do you use for the distribution cabinet transformers?
Large units use reinforced wooden cases, while small models use high-strength cartons for full international transit protection.
- Do you accept OEM/ODM orders with our brand logo?
Yes, we provide full OEM/ODM services, including custom logo printing on products, manuals and packaging for bulk orders.
- What are your main global markets?
Our distribution cabinet transformers are sold worldwide, covering Central Asia, East Asia, South Asia, Africa, South America and North America.
- What is your minimum order quantity (MOQ)?
Our MOQ is 1 set for both standard and custom distribution cabinet transformers.
- Can you customize voltage and capacity for my specific distribution project?
Yes, we fully customize voltage ratio, capacity, protection grade and design to match your factory, medical, photovoltaic or EV charging distribution needs.
